Included with the PCB Kit:

• 1 - ScottoT9 PCB
• 1  - 128x64 OLED
• 1 - RP2040 Zero
• 14 - 1N4148W SOD-123 diodes
• 4 - M2x3mm countersunk screws
• 8 - M2x4mm pan head screws
• 4 - M2x4mm standoffs
• 4 - M2 paper washers
• 1 - Plexiglass OLED cover

If purchasing the case, it includes:

• 1 - 3D printed case
• 1 - 3D printed plate
• 4 - Rubber feet

If purchasing the 3D printed keycaps, they include:

• 2 - 1.5u flat

• 12 - 1u flat

You will need the following to complete the build:

• 14 - Choc V1 switches
• 14 - 18x17mm Choc V1 keycaps (if not purchasing)
  • 2 - 1.5u
  • 12 - 1u
• 1 - 3D Printed case (if not purchasing)

Files

1. vial.uf2 - Basic QMK keymap with Vial support and no T9 stuff.
2. scotto.uf2 - The T9 keymap with all the tap dance features.

3. Code - Source code including Vial keymap.

4. Case - Case and keycap files to 3D print yourself.

Specifications

• Length: ~73mm
• Depth: ~107mm
• Height: ~16mm (with ScottoCaps)
• Spacing: 18x17mm Choc V1

Customization

If you want something in a different color, please contact us.
